Floater

Floater

Easy to use

Precise electrolyte level

Just as our filling plugs are different, we also offer a variety of sizes of matching floats. There are 2 diameter series as standard, each with 7 and 8 lengths to suit your battery perfectly.

We have been convinced of this system for decades and therefore offer a lifetime guarantee on our floats

Our floats consist of a two-piece design that includes a robust, color-coded outer casing and a foam core. This clever design offers numerous advantages: The foam buoyancy core remains sealed at all times and provides a reliable attachment to the plug. Each color corresponds to a specific length – be it for the 18 mm or the 23 mm series. The colors are clearly visible and prevent confusion. This means that correct identification is possible at a glance, even if parts are accidentally placed in the wrong storage location or sorted incorrectly in the warehouse. This provides additional safety

The hard outer housing protects the foam core from damage that can occur with other suppliers when a hydrometer is used for acid testing. Once inserted into the plug, the hydrometer tube slides to the side thanks to the smooth surface of the housing and cannot puncture or damage the buoyancy foam.

18mm

Not available

RED

Dimension

B = 44

23mm

Artical No. 0244

18mm

Artical No. 0148

GREEN

Dimension

B = 48

23mm

Artical No. 0248

18mm

Artical No. 0152

BLACK

Dimension

B = 52

23mm

Artical No. 0252

18mm

Artical No. 0156

GREY

Dimension

B = 56

23mm

Artical No. 0256

18mm

Artical No. 0160

YELLOW

Dimension

B = 60

23mm

Artical No. 0260

18mm

Artical No. 0166

BLUE

Dimension

B = 66

23mm

Artical No. 0266

18mm

Artical No. 0171

ORANGE

Dimension

B = 71

23mm

Artical No. 0171

18mm

Not available

PURPLE

Dimension

B = 75

23mm

Artical No. 0275

How to use our float gauge


How you can determine your Float

A

Elektrolyte level

The final distance beween the electrolyte level and the cell opening after fill cap stops inflow of watere

B

Float lenght

The distance between the bottom of the fill cap washer and the bottom of the float

C

Min required distance between cell opening and plates

The minimum distance that must exist between the battery cell opening and its plates or moss shield is the „FLOAT LENGTH+safety distance

Most batteries have an elektrolyt minimum Level of 3mm above the plates and a maximimum level of 31 mm measured from the rim of the vent opening.

We recommend keeping the elektrolyt level below its specified maximum to avoid the rsik of overflowing

The clearance between the bottom of the float and the plates has to be at least 5mm!

Measurements table

Fill cap push in 35 mm

Length & No. 4448525660667175
A3438424650566065
B4751555963697478
C5258606470747983

Measurements table

Fill cap with adapter
1/4 Turn (bayonet) 1/8Turn (bayonet) Clip-in (bayonet) M21-M30 Thread

Length & No.4448525660667175
A1822263934404549
B3135394347535862
C3640444852586367
